Pacific Warbirds Airplane
"The North American SNJ

North American Aviation
“Conventional design, two place tandem, low wing, all metal, single engine, land plane with retractable landing gear.  Wing structure is conventional, with at two-spar system.  Split flap system is a hydraulically actuated.  The fuselage is chrome-molybdenum tube truss to the rear of the aft cockpit, with a wood or semi-monocoque structure after that.  Later aircraft have wood stabilizers.”

SNJ-5B Specifications
Span
Length
Height
Wing Area
Tread
Empty weight
Design weight
Max takeoff/landing weight
Electrical
Fue - 2 wing tanks
Fuel grade – AN-F-48
Oil – AN-O-8
EnginePratt & Whitney
Super Charger
Brake Horsepower
Propeller Hamilton Standard
Ordinance – 30 caliber Guns

Bombs
42.0 feet
29.0 feet
14 feet, 6 inches
253.7 square feet
8 feet 7 inches
4082 pounds
5600 pounds
5500 pounds
24 volts
110 gallons
91/96 octane
10 gallons
R-1340-AN-1
1 Stage 1 Speed
600 @ 2250 rpm
2 Blade – 9’ 0”
Cowl – 200 rounds
Rear – 500 rounds
Wing – 10, 20 pound
Wing – 4, 100 pound
